Supports Geo-fencing function
Find the device (LED light flash and buzzer)
SOS alarm
Two-way voice calling
Low power / overspeed / vibration alarm
Group management
Mileage statistics
Supports flexible working mode
Product Details
Working temperature: -20℃~+70℃
Operating Humidity: 20%~80%RH
Waterproof: IP66
Color: Black and White
Dimensions: 60*40*21mm
Battery: 800mAh
new content
Supports 4G CAT1/CATM+EGPRS data transfer
Built-in high-sensitivity GPS + AGPS rapid positioning
Supports AT commands for easy and fast development
Communicates via SMS/TCP
Historical track and playback
OTA firmware upgrading
Data buffer storage 100 points
Supports 3-axis accelerometer
GPRS transmission protocol: TCP/IP
Operating voltage: 3.4-4.2V DC
GPS chipset: AT6558R
GPS accuracy: ≤2.5m (CEP50)
GNSS systems supported: GPS, GLONASS, BeiDou, Galileo, QZSS
GPS sensitivity:
Trace: -157 dBm,
Re-acquisition: -157 dBm,
Acquisition: -148 dBm
GPS start time:
Cold start TTFF: <32s,
Hot start TTFF: <1s,
Normal temperature start TTFF: <1s
